Stabila, 07340, Laser Receiver, Waterproof and Dustproof, Two-Sided Digital Display, Operating Life 24 h, Receiving Spectrum 500-680

Laser receiver for accurately determining the beam position of rotary lasers with red or green laser diodes – even over large distances. Two-sided digital display for fast work – illuminated at the touch of a button. Visual display: Arrow symbols on the display indicate the position of the receiver relative to the reference plane of the laser. Acoustic guidance can be activated with beeping tones for which the volume can be set. Two sensitivity levels can be set for application-oriented work – “fine grade” with a sensitivity of ± 1/32 in (± 1 mm) or “coarse grade” with a sensitivity of ± 1/8 in (± 3 mm). Waterproof and dustproof in accordance with protection class IP 67. Receiver bracket for attaching to leveling rods. Battery status display. Height of receiving area: 3 1/8 in (80 mm). Battery life: 24 hours.

Features

• For measurements over large distances – suitable for rotary lasers with green or red diodes
• Acoustic and visual guidance
• How true pro's measure
• Two-sided digital display for fast work
• Waterproof and dustproof
• Versatile, high-performance receiver for rotary lasers with red or green laser beams

Specifications

• Min. operating temperature (Fahrenheit): 14 °F
• Max. storage temperature: 70 °C
• Protection class: IP 66
• CE marking: Yes
• Max. operating temperature (Fahrenheit): 122 °F
• Min. storage temperature: -20 °C
• Battery type: AA
• Min. operating temperature: -10 °C
• Max. storage temperature (Fahrenheit): 158 °F
• order: 4040135
• Receiving spectrum: 500-680
• Receiving area: 80 mm
• Max. operating temperature: 50 °C
• Min. storage temperature (Fahrenheit): -4 °F
• Manufacturer's guarantee: 2 Years
• Operating life: 24 h
• Number of batteries: 2 pc.
• Battery weight: 45 g
