Klein Tools, 1685-50C, Parallel Jaw Grip, 5 in Jaw Length, 0.3 to 0.8 in Cable Diameter, 10,000 lb Max Load

This lightweight, compact grip pulls guy strand and EHS cable sizes from 0.3-Inch to 0.8-Inch (8 to 20 mm). Designed with a round inside-jaw contour for maximum contact to minimize conductor damage. The aggressive jaw prevents slipping on guy strand. Spring-loaded for easy one-handed operation.

Warnings

• When used on/near energized lines, ground, insulate, or isolate grip before pulling.
• Do not exceed rated capacity.
• Before each use, clean jaw area and inspect grip for proper operation to avoid slippage.

Features

• 5-Inch (127 mm) jaw length increases surface area contact with the cable
• Made in USA
• For use on guy strand and EHS cable sizes from 0.3 to 0.8 inches (8 - 20 mm)
• Round Inside-jaw Contour
• Pulls 5/16-Inch to 3/4-Inch steel cables
• Sawtooth jaw profile resists build-up from galvanized coating on guy strand and EHS cables and spring helps maintain cable position in grips jaw

• Maximum Safe Load: 10,000 lb (4536 kg)
• Cable Diameter: 0.3 in to 0.8 in (7.62 to 20.3 mm)
• Cable Type: Guy Strand, EHS, Coated, Messenger
• Jaw Length: 5 in (12.7 cm)
• Overall Length: 11.365 in (28.9 cm)
• Width: 6.433 in
• Height: 2.015 in
• Depth: 11.365 in
• Jaw Type: Round
• Teeth Type: Coarse
• Material: Steel
• Spring: Yes
• Locking Handle: No
• Hot Latch: No
• Swing Latch: No
• Type: Parallel Jaw Grip
• Material Compatibility: Galvanized guy strand and EHS cables
• Nominal Guy Strand Size: 0.3 to 0.8 in
• Cable Size: 5/16 in to 3/4 in steel cables
• Jaw Profile: Sawtooth
• Inside Jaw Contour: Round
• Operation: Spring-loaded, one-handed
• Origin: Made in USA
